Professional breathalyzer CDP-8899 Led

399,00 329,75 without vat

Professional breathalyzer CDP-8899 LED

Highly reliable breathalyzer designed for police, health care or professional use. It incorporates the latest technological advances such as: optional Bluetooth printer, intuitive OLED touchscreen, high-capacity lithium battery, data Logger function with storage for up to 20,000 records, and advanced software to transfer data to a PC to perform statistical studies.

Highlights:

  • 8-inch OLED color touchscreen with touch keypad.
  • State-of-the-art electrochemical sensor. Accuracy: ± 0.005 at 0.05% BAC %
  • Front focal and ambient lighting LEDs.
  • 7V/2300mAh long-lasting lithium battery.
  • Storing test logs (up to 20,000).
  • Compact optional Bluetooth printer for data printing.
  • Selectable operating languages: Spanish, English and Portuguese.
  • Checking calibration cycle status with alert message.
  • K-factor adjustable in a range from 1800 to 2200 (default 2100 Spain).
  • Protective case with impact resistance manufactured ABS PA-777E.

In stock

Description

Professional breathalyzer CDP-8899 Led

Highly reliable breathalyzer designed for police, health care or professional use. It incorporates the latest technological advances such as: optional Bluetooth printer, intuitive OLED touchscreen, high-capacity lithium battery, data Logger function with storage for up to 20,000 records, and advanced software to transfer data to a PC to perform statistical studies.

Highlights

  • 8-inch OLED color touchscreen with touch keypad.
  • State-of-the-art electrochemical sensor. Accuracy: ± 0.005 at 0.05% BAC %
  • Front focal and ambient lighting LEDs.
  • 7V/2300mAh long-lasting lithium battery.
  • Storing test logs (up to 20,000).
  • Compact optional Bluetooth printer for data printing.
  • Selectable operating languages: Spanish, English and Portuguese.
  • Checking calibration cycle status with alert message.
  • K-factor adjustable in a range from 1800 to 2200 (default 2100 Spain).
  • Protective case with impact resistance manufactured ABS PA-777E.

This product has been designed, manufactured and tested according to rigorous international quality standards with respect to the OIML R 126 standard, following the recommendations regarding evidence breathalyzers. Since each country has its specific legislation, we recommend consulting local guidelines for authorized evidence use.

Description

Professional CDP 8899 LED breathalyzer with optional printer. This product has been designed, manufactured and tested according to rigorous international quality standards, and very specifically, with respect to OIML R 126 on recommendations regarding evidence breathalyzers.

General features

  • The CDP 8899 breathalyzer is equipped with state-of-the-art electrochemical fuel cell sensor. Interchangeable sensor module.
  • Fast activation sensor with accurate and stable long-term results.
  • Equipped with large touchscreen (2.80-inch OLED – illuminated) which includes digital keyboard for fast and easy data entry.
  • It has an optional Bluetooth printer to document all test data and the user.
  • Uses sterilized mouthpieces with anti-return system for optimal hygiene.
  • Equipped with rechargeable Lithium-type battery: Li battery, 3,7 V / 2300 mAh.
  • Continuous working autonomy > 10 hours, under normal conditions of use.
  • Intelligent blow flow detection system when testing. Discriminates against invalid evidence.
  • It has a PASSIVE mode function for compulsory testing and measuring emissions of alcoholic content over liquids. It offers the possibility to perform, at the user’s will, tests in passive mode, breath sample or air.
  • Real-time and temperature indication.
  • Selectable operating languages: Spanish, English and Portuguese.
  • Selectable result units:
    • mg/l air exhaled with K-factor adjustable in a range of 1800 to 2200 (default 2100 Spain).
    • g/l, % BAC, ‰ BAC.
    • Temperature scale (℃, ℉).
  • Memory with capacity of up to 20,000 full records. With PC download software. Access to supervisor key-protected software to prevent possible tampering.
  • Managing user and supervisor passwords.
  • Includes GPS that provides geographic information about testing (optional – on request).
  • It has a 4-digit retro-illuminated LCD display. Very clear and accurate, with simple and easy-to-read messages.
  • Equipped with front lighting LEDs to improve nighttime on-site operations or in dark places.
  • Other functions:
    • Auto power off.
    • Checking the next calibration cycle with alert message (recommended every 6 to 12 months).
    • Real-time battery status.
    • Adjustable alarm level.
  • Allows you to transfer logs obtained or saved in memory to a PC via USB (supplied with serial kit).
  • The information collected by the printed receipt is as follows:
    • Device reference.
    • Printed report number.
    • Date.
    • Time.
    • Ambient temperature.
    • Result.
    • Device status or mode.
    • Person tested.
    • Vehicle license plate.
    • Postal address.
    • Signature of the person tested.
    • Police Reference (badge number).
    • This information can be tailor-made for large projects.
  • It uses TUV certified sanitary mouthpieces made from high density polypropylene and equipped with an anti-return system that prevents inhaling from the equipment, thus preventing the spread of diseases, infections, etc.
  • Allows periodic re-calibration in cycles of 6 to 12 months. Includes calibration certificate with recommended date for future calibrations and reminder message.

Technical Specifications

  • Electrochemical sensor by fuel cell (Fuel Sensor).
  • Accuracy: ± 0.005 at 0.05% BAC %
  • Range of measurements: 0.000~2.000mg/L(0~440mg/100Ml 0.000~4.000g/L0.000~0.400%BAC?0.000~2.000‰BAC)
  • For measurement format in mg/l in air, K-factor is user adjustable in a range from 1800 to 2200.
  • Standard deviation under normal conditions of use and storage: 0.006 mg/L per month
  • Alarm level: adjustable in a wide range from 0.00 – 0.600 mg/L.
  • Blow time: adjustable between 1 and 5 seconds (default: < 5 sec.)
  • Response time: < 10 sec.
  • Operating temperature: 0℃ – 50℃, ≤95% RH.
  • Storage temperature: -30ºC – 80ºC.
  • Relative humidity: 20 to 90%.
  • Atmospheric pressure: 700 to 1300 hPa.
  • 80-inch OLED touchscreen.
  • Lithium Battery: 3.7v/2200mAh – Full Charging Time 4 hours – Autonomy >10 hours.
  • Internal memory capacity: 20,000 full logs downloadable to PC.
  • External Bluetooth printer with battery (optional).
  • Protective case with anti-impact resistance manufactured ABS PA-777E, with Rockwell Hardness R-115 level. equivalent to SHORE D-130.
  • Dimensions: 158mm X 73mm X 33mm.
  • Size: 225 grams.

The kit includes

  • Aluminum carrying case.
  • CDP 8899 Breathalyzer.
  • Battery charger with USB input and micro-USB output.
  • 15 sterilized mouthpieces.
  • USB cable for downloading data to PC.
  • Optional: Bluetooth printer with charger and 1 roll of thermal paper.

Note:

CDP has its own breathalyzer laboratory. We offer qualified technical and post-sales support, which is essential for the sale of these measuring devices that require periodic maintenance. We perform certified calibrations, parts replacement, certificates, etc. This model has been specially designed for healthcare and professional use. We have more than 20 years of experience, and are a top company in Europe in this field.
